Ruijie RG-ES08 8 Port Ethernet Unmanaged Desktop Switch
Key Features
- Type - Desktop Switch
- Number of Total Port - 8 Port
- PoE - No
- Manageability - Unmanaged
- Data Transfer Rate - 10/100 Mbps
- Form Factor - Desktop
Specification
| General | |
| Brand | Ruijie |
| Model | RG-ES08 |
| Type | Desktop Switch |
| Key Features | |
| Interface | 8 x 10/100M Base-T ports |
| Network & Connectivity | |
| Data Rate | 10/100 Mbps |
| Ports & Connector | |
| Total Port | 8 Port |
| Power | |
| Power Supply | DC 5.0V/ 600mA (External) |
| Power Consumption | <=3.5W |
| Physical Specification | |
| Color | Black |
| Form Factor | Desktop |
| Dimension | 144 x 85 x 23mm |
| Technical Specification | |
| Manageability | Unmanaged |
| Switching Capacity | 1 Gbps |
| Other | Operating mode: Half-duplex, full-duplex, auto-negotiation mode Support auto MDI/MDIX, Backplane bandwidth: 1.6Gbps, Packet forwarding rate: 1.1904Mpps, MAC address: 1K, Operating temperature: 0 to 40 Degree C, Storage temperature: -40 to 70 Degree C, Operating humidity: 10% - 90% RH, Storage humidity: 5% - 95% RH. |
| What's in the Box | |
| Packet Contents | 1 x Ruijie RG-ES08, 1 x User Manual |
| Warranty Information | |
| Warranty | 3 Year (Without Adapter) |
Description
The Ruijie RG-ES08 is an 8-port unmanaged desktop switch from the Ruijie Real-easy Series, designed for small enterprises, SOHO environments, and small-scale surveillance networks. Equipped with eight 10/100M Base-T RJ45 ports, it supports half-duplex, full-duplex, and auto-negotiation modes, along with auto MDI/MDIX for effortless device connections without the need for crossover cables. With a backplane bandwidth of 1.6Gbps, a packet forwarding rate of 1.1904Mpps, and support for up to 1K MAC addresses, it ensures smooth and stable data transmission for everyday networking needs.
Featuring a sleek black fanless design, the RG-ES08 operates silently, making it ideal for noise-sensitive spaces. It has low power consumption at ≤3.5W and offers a plug-and-play setup with zero configuration required, ensuring quick deployment and compatibility with various devices such as IP cameras, PCs, and printers. Backed by a 3-year warranty (adapter not included), the Ruijie RG-ES08 provides a reliable, simple, and cost-effective networking solution.
