C-Data CS3244GC 29-Port L2 Managed Switch
Key Features
- Type - Network Switch
- Number of Total Port - 29 Port
- PoE - No
- Manageability - Managed
- Network Standards - IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
- Data Transfer Rate - 10/100/1000 Mbps
- Form Factor - Rackmount
Specification
| General | |
| Brand | C-Data |
| Model | CS3244GC |
| Type | Network Switch |
| Key Features | |
| Indicator | ower, system, Link/Act, 1000M |
| Interface | 24 x 10/100/1000M RJ45 adaptive ports & 4 x GE Combo ports |
| Network & Connectivity | |
| Data Rate | 10/100/1000 Mbps |
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Ports & Connector | |
| Gigabit Port | 28 |
| SFP Port | No |
| Total Port | 29 Port |
| Power | |
| Power Supply | AC100-240V |
| Power Consumption | 24W |
| Physical Specification | |
| Color | Black |
| Fan | Fanless |
| Form Factor | Rackmount |
| Dimension | 440 x 220 x 44mm |
| Technical Specification | |
| Manageability | Managed |
| PoE | No |
| Switching Capacity | 56Gbps |
| Transmission Method | Strorage forwarding |
| Other | Storage temperature:-40degree to 70degree C, work temperature: 0 degree to 50 degree C work humidity; 10% to 90% storage humidity; 10% to 90%. Certification: FCC; CE;CB;UL. Port buffer: 4M Packets switching capability: 38.68Mpps SDRAM size: 128MB FLASH size: 16MB Console port: 1 pcs Jumbo frame: 10K |
| Specialty | Support abundant L2 features such as VLAN,LLDP,QoS,ACL Support CLI/SNMP/WEB UI Management. Storm control:Broadcast/Multicast/Unknown Unicast Storm Control |
| What's in the Box | |
| Packet Contents | 1 x C-Data CS3244GC, 1 x User manual |
| Warranty Information | |
| Warranty | 2 year |
Description
The C-Data CS3244GC is a 29-port managed Gigabit network switch designed for high-performance, secure, and flexible enterprise networking. It comes equipped with 24 adaptive 10/100/1000M RJ45 ports and 4 Gigabit Combo ports, delivering a total switching capacity of 56Gbps and a forwarding rate of 38.68Mpps for smooth, high-speed data handling.
Built for professional network management, it supports advanced Layer 2 features such as VLAN, LLDP, QoS, and ACL, along with storm control for broadcast, multicast, and unknown unicast traffic. It offers multiple management options including CLI, SNMP, and Web UI, making configuration and monitoring efficient and user-friendly.
The switch features a fanless rackmount design in a black metal chassis, measuring 440 x 220 x 44mm for standard 1U rack installations. It operates silently while maintaining stability in varied conditions, with a wide temperature tolerance from 0°C to 50°C (operating) and -40°C to 70°C (storage).
With 4MB port buffer, 128MB SDRAM, 16MB flash memory, and jumbo frame support up to 10K, it ensures efficient handling of large volumes of network traffic. Certified by FCC, CE, CB, and UL, the CS3244GC runs on an AC100-240V power supply with a low consumption of 24W.
Backed by a 2-year warranty, this switch is an excellent choice for medium to large networks that require high-capacity performance, rich management features, and dependable reliability.
