Huawei S220-24P4X 28 Port Managed eKit SMB Switch
Key Features
- Type - Network Switch
- Number of Total Port - 28 Port
- PoE - Yes
- Manageability - Managed
- Data Transfer Rate - 10/100/1000 Mbps
- Form Factor - 1U Rack-mountable
Specification
| General | |
| Brand | Huawei |
| Model | S220-24P4X |
| Type | Network Switch |
| Key Features | |
| Indicator | PWR, SYS (Steady on, Fast blinking, Slow blinking), PoE (Steady on), CLOUD (Fast blinking, Slow blinking) |
| Interface | 24 x 10/100/1000Mbps PoE+, 4 x 10GE SFP |
| MTBF | 527537.88 Hours |
| Network & Connectivity | |
| Data Rate | 10/100/1000 Mbps |
| Ports & Connector | |
| Gigabit Port | 28 |
| PoE+ Port | 24 |
| SFP Port | 4 |
| Total Port | 28 Port |
| Power | |
| Power Supply | 100 V AC to 240 V AC, 50/60 Hz, High-voltage DC input: 240 V DC |
| Power Consumption | 37.12 W (Typical), Without PoE: 44.35 W, Full PoE load: 485.91 W (PoE: 400 W) (Max.), 27.07W (Static) |
| Physical Specification | |
| Color | White |
| Connector Type | 24 x 10/100/1000 Mbps RJ45, 4 x 10/100/1000Mbps SFP |
| Fan | Yes |
| Form Factor | 1U Rack-mountable |
| Material | Metal |
| Weight | 2.92 Kg |
| Dimension | 43.6 x 442.0 x 220.0mm |
| Technical Specification | |
| Manageability | Managed |
| Memory | 2GB |
| PoE | Yes |
| What's in the Box | |
| Packet Contents | Huawei S220-24P4X Switch, User Manual, Warranty Card |
| Warranty Information | |
| Warranty | 1 Year (Without Adapter) |
Description
The Huawei S220-24P4X is a high-performance, managed network switch designed for enterprise environments requiring reliable Power over Ethernet (PoE+) capabilities and high-speed connectivity. It offers a total of 28 ports, comprising 24 Gigabit PoE+ Ethernet ports and 4 10GE SFP uplink ports, allowing seamless integration of high-bandwidth devices and expansion in demanding network setups.
Powered by a dual-core 1.1 GHz CPU and equipped with 2GB of memory and 1GB flash storage, this switch supports advanced Layer 2 and Layer 3 networking features, delivering efficient traffic management and network security. Its sturdy metal build and white finish are tailored for 1U rack mounting, making it a robust solution for data centers and enterprise racks.
With a fan-cooled design featuring two built-in fans and intelligent fan speed adjustment, the switch maintains optimal thermal conditions while managing noise levels (typical acoustic power noise: 49.3 dB(A)). It supports a broad operating temperature range from -5°C to 50°C and operates efficiently at altitudes up to 5000 meters, ensuring adaptability in diverse physical environments.
The device offers a typical power consumption of 37.12W, which can rise to a maximum of 485.91W under full PoE load (delivering up to 400W PoE power). It incorporates comprehensive surge protection for service and power ports, guaranteeing network stability and device safety.
With a mean time between failures (MTBF) of over 527,000 hours and high availability (>99.999%), the Huawei S220-24P4X provides reliable and continuous network service. Its intuitive LED indicators display real-time status for power, system health, PoE operation, and cloud connectivity.
Ideal for enterprises looking to power and connect a wide array of devices like IP cameras, VoIP phones, and wireless access points, the Huawei S220-24P4X combines powerful PoE functionality with high-speed uplinks and advanced management features.
