Ruijie RG-ES08G 8 Port Gigabit Unmanaged Desktop Switch
Key Features
- Type - Desktop Switch
- Number of Total Port - 8 Port
- PoE - No
- Manageability - Unmanaged
- Data Transfer Rate - 10/100/1000 Mbps
- Form Factor - Desktop
Specification
| General | |
| Brand | Ruijie |
| Model | RG-ES08G |
| Type | Desktop Switch |
| Key Features | |
| Interface | 8 x 10/100/1000M Base-T ports |
| Network & Connectivity | |
| Data Rate | 10/100/1000 Mbps |
| Ports & Connector | |
| Gigabit Port | 8 |
| Total Port | 8 Port |
| Power | |
| Power Supply | DC 9.0V/ 600mA (External) |
| Power Consumption | <=6.5W |
| Physical Specification | |
| Color | Black |
| Form Factor | Desktop |
| Material | Plastic |
| Dimension | 144 x 85 x 23mm |
| Technical Specification | |
| Manageability | Unmanaged |
| Other | Operating temperature: 0 to 40 Degree C, Storage temperature: -40 to 70 Degree C, Operating humidity: 10% - 90% RH, Storage humidity: 5% - 95% RH, MAC address: 4K, Packet forwarding rate: 11.904Mpps, Backplane bandwidth: 16Gbps, Operating mode: Half-duplex, full-duplex, auto-negotiation mode Support auto MDI/MDIX |
| What's in the Box | |
| Packet Contents | 1 x Ruijie RG-ES08G, 1 x User Manual |
| Warranty Information | |
| Warranty | 3 Year (Without Adapter) |
Description
The Ruijie RG-ES08G is an 8-port unmanaged Gigabit desktop switch from the Ruijie Real-easy Series, designed for small enterprises, SOHO setups, and small-scale surveillance networks. It features eight 10/100/1000M Base-T RJ45 ports with support for half-duplex, full-duplex, and auto-negotiation modes, along with auto MDI/MDIX for hassle-free connections without crossover cables. With a backplane bandwidth of 16Gbps, a packet forwarding rate of 11.904Mpps, and a 4K MAC address table, it delivers high-speed, stable performance for demanding networking needs.
Built with a sleek black plastic housing, the RG-ES08G offers fanless, silent operation and low power consumption at ≤6.5W. It is designed for quick and easy deployment, featuring true plug-and-play functionality with zero configuration required, and is compatible with a wide range of devices such as IP cameras, PCs, printers, and more. Part of Ruijie’s finely crafted Real-easy Series, it combines enterprise-grade quality, energy efficiency, and strong adaptability for various scenarios. Backed by a 3-year warranty (adapter not included), the Ruijie RG-ES08G is a reliable and efficient choice for high-speed desktop networking.
