UNIKA UN-H81M PRO M.2 V1.0 DDR3 4th Gen Micro ATX Motherboard

Price: 4,800৳
Regular Price: 5,800৳
Status: In Stock
Brand: Unika

Key Features

  • Platform: Intel Platform
  • Chipset: Intel H81
  • Form Factor : Micro ATX
  • CPU Socket Type: LGA 1150
View More Info

Payment Options

Specification

General
Brand UNIKA
Model UN-H81M PRO M.2 V1.0
Memory
Slots 2 x DDR3 memory slots
Maximum Memory 16 GB
Supported Memory DDR3 1600/1333/1066 memory* (actual memory data transfer speed depends on processor type and memory module)
Basic Information
Chipset Intel H81
Form Factor Micro ATX
Supported CPU Intel Core i7/i5/i3/Pentium/Celeron LGA1150 (support Intel 22nm processor)
Expansion Slots
PCI 1 x PCI-E x 16 graphics card slot; 1 x PCI-E x 1 slot
Ports & Connector
Audio Onboard Realtek ALC897 high-fidelity audio independent sound card
HDMI 1 X HDMI Display OutputLAN Port (s)
LAN Port (s) Onboard Realtek 8111H Gigabit network card; 1 x M.2 wifi interface
Supported Storage 4 x SATA3.0 6Gb/s M.2 Interface: 1 x M.2 slot, supports 2242/2260/2280 type storage devices
USB (s) 2 x USB 3.0 ports at the rear; 4 x USB 2.0 ports; 1 x USB 3.0 header at the front, 2 USB 3.0 ports can be expanded; 1 x USB 2.0 header, 2 USB 2.0 ports can be expanded
Warranty Information
Manufacturing Warranty 03 years

Description

The UNIKA UN-H81M PRO M.2 V1.0 DDR3 Micro ATX Motherboard supports Intel's 4th generation Core i7, i5, i3, Pentium, and Celeron processors with an LGA1150 socket. Built on the Intel H81 chipset, it features two DDR3 memory slots supporting speeds of 1600, 1333, and 1066 MHz, with a maximum capacity of 16 GB. The motherboard includes one PCI-E x16 slot for graphics cards and one PCI-E x1 slot. For storage, it provides four SATA3.0 ports and one M.2 slot that supports 2242/2260/2280 type storage devices. Connectivity options are robust, with rear USB 3.0 and 2.0 ports, as well as headers for additional USB ports. Display outputs include DisplayPort, HDMI, and VGA. It also has an onboard Realtek 8111H Gigabit network card and Realtek ALC897 high-fidelity audio chip. Additional features include PS/2 ports, RJ45 network port, and various audio ports.

Availability and Usability

The UNIKA UN-H81M PRO M.2 V1.0 DDR3 Micro ATX Motherboard is available at SkyLandBD, providing a reliable and efficient solution for building or upgrading PCs. This motherboard's compatibility with Intel's 4th generation processors and comprehensive connectivity options make it suitable for both personal and professional use. For those searching for the best "UNIKA UN-H81M PRO M.2 V1.0 DDR3 4th Gen Micro ATX Motherboard Price in BD," SkyLandBD offers competitive pricing and excellent customer service.

Highlights

  • Supports Intel 4th Gen Core i7/i5/i3/Pentium/Celeron processors
  • DDR3 memory slots with speeds up to 1600 MHz
  • PCI-E x16 and M.2 slots for graphics and storage
  • Multiple display outputs: DisplayPort, HDMI, VGA
  • Onboard Realtek Gigabit network and high-fidelity audio
