MAXSUN Challenger B760M-F D5 12th/13th Gen Motherboard
Key Features
- Chipset: INTEL B760
- Form Factor: M-ATX
- Supported CPU: 12th/13th Gen Intel LGA 1700
- LAN: Realtek RTL8111H 1G LAN
Specification
| General | |
| Brand | MAXSUN |
| Model | Challenger B760M-F |
| Memory | |
| Memory | 2x DDR5, Maximum Memory Capacity 96GB Memory Support DDR5 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Supports Intel® XMP 3.0 OC Supports Dual-Controller Dual-Channel Mode |
| Graphics | |
| Graphics | 1x VGA *Support VGA, Maximum Resolution Of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz 1x HDMI Port *HDMI™ Port Supports Up To 4K@30Hz |
| Basic Information | |
| Chipset | INTEL B760 |
| Form Factor | M-ATX |
| Supported CPU | Supports 12th/13th Gen Intel Core Processors, Pentium® Gold And Celeron Processors LGA 1700 |
| Ports & Connector | |
| Internal I/O Ports | 1x 24-Pin Power Connector(ATX_PWR) 1x 8-Pin Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2 X M.2 Slots (Key-M) 3x SATA 6Gb/S Ports 1x 2-Pin CLR_CMOS 1x 4-Pin BUZZER 1x Front Audio 1x COM_A Port 1x 2-Pin F_PANEL 1x TPM Pin Header(Support TPM 2.0) 1x 3-Pin SPDIF 1x 12V 4-Pin RGB |
| LAN Port (s) | Realtek RTL8111H 1G LAN |
| PCI Card Slot | 1x PCIe 4.0 X16 Slot 1x PCIe 3.0 X4 Slot |
| USB (s) | Front USB (Total 6 Ports) 2x USB 3.2 Gen1 Type A 4x USB 2.0 *Rear USB (Total 6 Ports) 4x USB 3.2 Gen1 Type A 2x USB 2.0 |
| Physical Specification | |
| Dimension | 245mm X 190mm |
| Warranty Information | |
| Warranty | 03 Years |
Description
Reviews (0)
Get specific details about this product from customers who own it.
Frequently Asked Questions (FAQs)
Common questions and answers regarding MAXSUN Challenger B760M-F D5 12th/13th Gen Motherboard
What is the price of MAXSUN Challenger B760M-F D5 12th/13th Gen Motherboard in Bangladesh? expand_more
The latest price of MAXSUN Challenger B760M-F D5 12th/13th Gen Motherboard in Bangladesh is 8,799৳. You can purchase it at the best price from our website or visit any of our Skyland Computer outlets.
Is MAXSUN Challenger B760M-F D5 12th/13th Gen Motherboard currently in stock at Skyland? expand_more
Yes, MAXSUN Challenger B760M-F D5 12th/13th Gen Motherboard is currently In Stock at Skyland. You can order online for fast home delivery across Bangladesh or in-store pickup.
What warranty comes with MAXSUN Challenger B760M-F D5 12th/13th Gen Motherboard? expand_more
This product comes with official brand warranty as detailed in the technical specifications. Skyland Computer ensures 100% genuine products with official service and warranty support.
