GIGABYTE Z790M AORUS ELITE AX mATX Motherboard

Name: GIGABYTE Z790M AORUS ELITE AX mATX Motherboard
Brand: Gigabyte
SKU: Z790M AORUS ELITE AX
Price: 35200.00 BDT
Availability: InStock

Price: 35,200৳

Regular Price: 39,060৳

Status: In Stock

Brand: Gigabyte

Key Features

Supported CPU: 14th Gen, 13th Gen & 12th Gen Processors (LGA1700)
Supported RAM: 4 x DDR5 DIMMs, up to 7600(O.C.)
Graphics Output: 1 x HDMI, 1 x DisplayPort
Features: 2.5GbE LAN & Wi-Fi 6E 802.11ax

View More Info

Payment Options

35,200৳ 39,060৳

Cash Discount Price

Online / Cash Payment

Special Price: 35,200৳

View Banks EMI Plans

Specification

General
Brand	GIGABYTE
Model	Z790M AORUS ELITE AX
Memory
Type	DDR5
Slots	4 x DIMM sockets
Maximum Memory	128GB (32 GB single DIMM capacity)
Supported Memory	Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Graphics
Graphics	Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 * Support for DisplayPort 1.2 version and HDCP 2.3
Basic Information
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset	Intel Z790 Express Chipset
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Supported CPU	LGA1700 socket: Support for the 14th Gen, 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU
Expansion Slots
PCI	CPU: 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2) Support for AMD CrossFire technology (PCIEX16 and PCIEX4)
Ports & Connector
Audio	2 x audio jacks
Display Port (s)	1 x DisplayPort
HDMI	1 x HDMI
Internal I/O Ports	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 4 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt add-in card connectors 1 x reset button 1 x Q-Flash Plus button 1 x Clear CMOS button 1 x reset jumper 1 x Clear CMOS jumper
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
RAID	RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Supported Storage	CPU: 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB) 6 x SATA 6Gb/s connectors
TPM (Trusted Platform Module)	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
USB (s)	Chipset: 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2x2 support 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Wireless Communication module	Intel Wi-Fi 6E AX211 WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Others
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Other Features
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Warranty Information
Manufacturing Warranty	3 years

Description

The GIGABYTE Z790M AORUS ELITE AX mATX Motherboard is a high‑performance Intel Z790 chipset board built for 14th, 13th, and 12th Gen Intel Core processors on the LGA1700 socket, offering next‑generation features like DDR5 memory support up to 7600 MHz (OC), PCIe 5.0 readiness for GPUs and NVMe SSDs, and advanced thermal solutions for stable performance in compact builds. Designed in the micro‑ATX form factor, it combines powerful functionality with space‑saving efficiency, featuring a robust Twin 12+1+1 Hybrid Digital VRM design, 8+4 solid pin power connectors, and a 6‑layer 2X copper PCB for reliable power delivery. Storage expansion is future‑proof with triple PCIe 4.0 M.2 slots equipped with Thermal Guard protection and EZ‑Latch Plus for easy installation, while connectivity includes Wi‑Fi 6E, Gigabit LAN, multiple USB 3.2 Gen2/Gen1 ports, and USB‑C for modern devices. The rear I/O offers HDMI and DisplayPort outputs, and onboard audio powered by high‑definition codecs ensures immersive sound quality. Enhanced with RGB Fusion lighting, Ultra Durable Armor on DDR5 slots, and GIGABYTE Control Center software, the Z790M AORUS ELITE AX delivers both style and reliability. Compact yet versatile, this Gigabyte Z790M AORUS Motherboard is ideal for gamers, creators, and professionals seeking a Gigabyte DDR5 Motherboard with premium features, seamless connectivity, and future‑ready performance, making it a standout choice among Gigabyte WiFi Motherboards in Bangladesh and beyond.

Buy GIGABYTE Z790M AORUS ELITE AX mATX Motherboard from SkylandBD

In Bangladesh, you can get original GIGABYTE Z790M AORUS ELITE AX mATX Motherboard From SkylandBD. We have a large collection of the latest GIGABYTE Motherboard to purchase for your Desktop PC. Order Online Or Visit your Nearest SkylandBD Shop to get yours at the lowest price. The GIGABYTE Z790M AORUS ELITE AX mATX Motherboard comes with 3 years of warranty.
