GIGABYTE H410M H V2 10th Gen Micro ATX Motherboard

Name: GIGABYTE H410M H V2 10th Gen Micro ATX Motherboard
Brand: Gigabyte
SKU: H410M H V2

Status: Out Of Stock

Product Code: H410M H V2

Brand: Gigabyte

Key Features

Supported CPU: 10th Gen Intel Core Processors
Supported RAM: DDR4, 2 DIMMs, up to 64 GB
Graphics Output: 1 x D-Sub, 1 x HDMI
Features: Intel GbE LAN with cFosSpeed

View More Info

Order / Inquiry on WhatsApp Messenger

0% EMI up to ৳15,000 on 27+ Banks Avail instant monthly installments on credit cards with SSLCOMMERZ. Charges apply on EMI above ৳15,000.

Official Warranty Nationwide Delivery Cashback Offer

Specification

General
Brand	GIGABYTE
Model	H410M H V2
Memory
Type	DDR4
Slots	2 x DIMM
Maximum Memory	64GB (32 GB single DIMM capacity)
Supported Memory	Intel Core i9/i7 processors: Support for DDR4 2933/2666/2400/2133 MHz memory modules Intel Core i5/i3/Pentium/Celeron processors: Support for DDR4 2666/2400/2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Graphics
Graphics	Integrated Graphics Processor-Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI ports, supporting a maximum resolution of 4096x2160@30 Hz * Support for HDMI 1.4 version and HDCP 2.3.
Max Shared Memory	512MB
Basic Information
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset	Intel H470 Express Chipset
Form Factor	Micro ATX Form Factor: 22.6cm x 18.5cm
Supported CPU	Support for 10th Generation Intel Core i9 processors/ Intel Core i7 processors/ Intel Core i5 processors/Intel Core i3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1200 package
Expansion Slots
PCI	1 x PCI Express x16 slot, running at x16 2 x PCI Express x1 slots (The PCI Express slots conform to PCI Express 3.0 standard.) Supports up to ASPM L1.2 power management protocols.
Ports & Connector
D-Sub (s)	1 x D-Sub port
HDMI	1 x HDMI port
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x RGB LED strip header 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x serial port header 1 x Clear CMOS jumper
LAN Port (s)	Intel GbE LAN chip (1 Gbit/100 Mbit)
RAID	Support for RAID 0, RAID 1, RAID 5, and RAID 10
Supported Storage	1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) 4 x SATA 6Gb/s connectors Intel Optane Memory Ready M.2 connectors support up to ASPM L1.2 PCIe power management protocols.
TPM (Trusted Platform Module)	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
USB (s)	Chipset: 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
Others
Bundled Software	Norton Internet Security (OEM version) cFosSpeed
Other Features
Special Features	Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS Ambient LED EasyTune Fast Boot Game Boost ON/OFF Charge Smart Backup System Information Viewer Support for Q-Flash Support for Xpress Install
Warranty Information
Manufacturing Warranty	03 Years

Description

GIGABYTE H410M H V2 10th Gen Micro ATX Motherboard

The GIGABYTE H410M H V2 Micro ATX Motherboard, designed to support Intel’s 10th Generation processors. This compact and reliable board offers two DDR4 DIMM slots with support for memory speeds up to 2933MHz, making it ideal for mainstream gaming or productivity setups.

Dual Display Support
Whether you’re multitasking or gaming, the motherboard offers both HDMI and D-Sub outputs, enabling dual monitor setups straight out of the box.

High-Definition Audio
Enjoy immersive sound with 8-channel HD Audio backed by premium-grade audio capacitors. GIGABYTE’s design also includes an audio noise guard that helps isolate sound signals from PCB-level interference for cleaner audio quality.

High-Speed Storage with M.2
For faster boot times and data transfers, the board includes an NVMe PCIe Gen3 x4 2280 M.2 slot, providing blazing fast SSD support for modern workflows and gaming.

Reliable Networking with Intel GbE LAN
Experience smooth and low-latency online performance thanks to the integrated Intel Gigabit Ethernet with cFosSpeed Internet Accelerator, which helps manage network traffic and reduce lag in busy environments.

Smart Cooling with Smart Fan 5
Keep your system cool and silent with Smart Fan 5 technology, allowing you to control fan behavior based on temperature sensors across the board. Hybrid fan headers support both PWM and Voltage fans, and the Fan Stop feature lets you stop specific fans entirely when temperatures are low.

Easy BIOS Interface
Setting up your system is now easier than ever. The revamped GIGABYTE BIOS comes with an intuitive graphical interface and user-friendly options, helping you configure your PC with ease and confidence.
