GIGABYTE B650M GAMING PLUS WIFI DDR5 AM5 Motherboard

Name: GIGABYTE B650M GAMING PLUS WIFI DDR5 AM5 Motherboard
Brand: Gigabyte
SKU: B650M GAMING PLUS WIFI
Price: 20749.00 BDT
Availability: InStock

Price: 20,749৳

Regular Price: 24,000৳

Status: In Stock

Brand: Gigabyte

Key Features

Supported CPU: Ryzen 9000/ 8000/ 7000 Series Processors for Socket AM5
Supported RAM: 4x DDR5, up to 192GB, 7600(OC)
Graphics Output: 2x Display Port, 1x HDMI
Features: Realtek 2.5GbE LAN & Realtek Wi-Fi 6E RTL8852CE

View More Info

Payment Options

20,749৳ 24,000৳

Cash Discount Price

Online / Cash Payment

Special Price: 20,749৳

View Banks EMI Plans

Specification

General
Brand	GIGABYTE
Model	B650M GAMING PLUS WIFI
Memory
Type	DDR5
Slots	4x DIMMs
Maximum Memory	Up to 256 GB (64 GB single DIMM capacity) of system memory
Supported Memory	7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/4800/4400 MT/s memory modules Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
Graphics
Graphics	Onboard Graphics Integrated Graphics Processor with AMD Radeon Graphics support - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version. - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support for native HDMI 2.1 TMDS compatible ports. Support for up to triple-display at the same time (Graphics specifications may vary depending on CPU support.)
Basic Information
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset	AMD B650
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Supported CPU	AMD Socket AM5, support for: AMD Ryzen 8000/ 7000 Series Processors
Expansion Slots
PCI	1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. Chipset: - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)
Ports & Connector
Audio	3 x Audio jacks
Display Port (s)	2 x DisplayPorts
HDMI	1x HDMI
Internal I/O Ports	Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 2 x addressable LED strip headers 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x USB Type-C® port, with USB 3.2 Gen 1 support 3 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x HDMI port 2 x DisplayPorts 2 x SMA antenna connectors (2T2R) (1T1R)* * Only for Realtek Wi-Fi 6 RTL8851BE 1 x RJ-45 port 3 x audio jacks
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
RAID	RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Supported Storage	1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580 SSDs: AMD Ryzen 7000 Series Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs 4 x SATA 6Gb/s connectors
TPM (Trusted Platform Module)	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
USB (s)	CPU: - 1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support - 1 x USB 3.2 Gen 1 port on the back panel - 1 x USB 2.0/1.1 port on the back panel Chipset: - 2 x USB 3.2 Gen 1 ports on the back panel - 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header - 2 x USB 3.2 Gen 1 ports available through the internal USB header - 5 x USB 2.0/1.1 ports (1 port on the back panel, 4 ports available through the internal USB headers)
Wireless Communication module	Wireless Communication module Realtek Wi-Fi 6E RTL8852CE (PCB rev. 1.0) - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 160MHz wireless Realtek Wi-Fi 6 RTL 8851BE (PCB rev. 1.1) - WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 80MHz wireless (Actual data rate may vary depending on environment and equipment.)
Others
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Other Features
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus
Warranty Information
Manufacturing Warranty	03 Years

Description

GIGABYTE B650M GAMING PLUS WIFI DDR5 AM5 Motherboard

The GIGABYTE B650M GAMING PLUS WIFI DDR5 AM5 Motherboard is engineered for gamers, creators, and performance enthusiasts who demand next-gen speed and reliability. Designed for AMD Ryzen 7000, 8000, and 9000 Series processors, this Micro-ATX board features AMD AM5 socket compatibility, bringing future-ready performance and support for the latest computing technologies. This motherboard delivers rock-solid power through its 5+2+2 Phases Digital VRM Solution, ensuring efficient and stable power delivery even under heavy gaming or multitasking loads. Dual-channel DDR5 memory support with up to four SMD DIMM slots provides blazing speeds, enhanced bandwidth, and compatibility with AMD EXPO and Intel XMP profiles for effortless overclocking. For lightning-fast data access, the B650M GAMING PLUS WIFI includes a PCIe 4.0 x4 M.2 connector, ideal for NVMe SSDs and quick game or OS loading. The PCIe EZ-Latch x16 slot makes GPU installation or upgrades simple and tool-free. Enjoy next-gen connectivity with built-in Wi-Fi 6E (802.11ax) for ultra-fast wireless networking and 2.5GbE LAN for high-speed, low-latency wired connections. With dual DisplayPort outputs and HDMI, the board supports flexible multi-monitor setups. Smart Fan 6 cooling ensures thermal efficiency, using multiple temperature sensors and hybrid fan headers with FAN STOP for quiet, adaptive cooling. Plus, Q-Flash Plus enables BIOS updates without installing the CPU, memory, or GPU—streamlining system setup and maintenance. Built with GIGABYTE Ultra Durable components, the B650M GAMING PLUS WIFI is a compact powerhouse for creating a stable, fast, and upgrade-ready AMD system.
