Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard

Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Save: 3,501৳
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
Talk to Expert
01978094107
Messenger
We’d Love to Hear from You
Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard
0 reviews • Write a review
  • Price: 25,999৳
  • Regular Price: 29,500৳
  • Stock: In Stock
  • Brand: Gigabyte
  • Model: B650M AORUS ELITE AX ICE

Key Features

  • Micro-ATX Form Factor
  • AMD B650 Chipset
  • AM5 Socket
  • 4 x Dual-Channel DDR5 Slots
View More Info

Payment Options

25,999৳29,500৳

Cash Discount Price

Online / Cash Payment
—/month

Regular Price: —

Compare Bank EMI Options
Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Specifications

General
Brand Gigabyte
Model B650M AORUS ELITE AX ICE
Memory
Memory Support for DDR5 8000(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/ 6800(OC)/6666(OC)/6600(OC)/6400(OC)/6200(OC)/ 6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules,
Graphics
Graphics Integrated Graphics Processor with AMD Radeon™ Graphics support: - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version and HDR. - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support for native HDMI 2.1 TMDS compatible ports. (Graphics specifications may vary depending on CPU support.)
Software
Operating System Support for Windows 11 64-bit Support for Windows 10 64-bit
Basic Information
BIOS 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset AMD B650
Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
Storage 1 x M.2 connector (M2A_CPU), integrated into the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen™ 7000 Series Processors support PCIe 5.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Audio & Microphone
Audio Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
External Features
Expansion Slots 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
I/O Port 1 x Q-Flash Plus button 2 x SMA antenna connectors (2T2R)jk 1 x DisplayPort 1 x HDMI port 1 x USB Type-C® port, with USB 3.2 Gen 2 support 2 x USB 3.2 Gen 2 Type-A ports (red) 5 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 1 x optical S/PDIF Out connector 2 x audio jacks
Network & Connectivity
Wireless Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.0) - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 160MHz wireless standard Intel® Wi-Fi 6E AX210 (PCB rev. 1.1) - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 160MHz wireless standard
Operating System
CPU AMD Socket AM5, support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
Ports & Connector
Internal I/O Ports 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x THB_U4 add-in card connector 1 x Trusted Platform Module header (For the GC- TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only) 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper
LAN Port (s) Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
USB (s) CPU: - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel CPU + USB 2.0 Hub: - 4 x USB 2.0/1.1 ports on the back panel Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header - 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header) - 4 x USB 2.0/1.1 ports available through the internal USB headers Chipset+USB 3.2 Gen 1 Hub: - 4 x USB 3.2 Gen 1 ports on the back panel
Warranty Information
Warranty 03 years

Description

Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard

The Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard is a powerful and stylish motherboard designed for modern AMD builds. Built on the AMD B650 chipset and compatible with Ryzen 7000, 8000, and 9000 Series processors, it delivers exceptional performance for gaming, content creation, and productivity. Featuring a robust 12+2+2 phase digital VRM design and advanced thermal management with large heatsinks and M.2 Thermal Guards, it ensures stable power delivery and efficient cooling during heavy workloads. With support for DDR5 memory up to 256GB and speeds up to 8000MT/s (OC), it enables fast data transfer and smooth multitasking. This motherboard includes one PCIe 5.0 x4 M.2 slot and one PCIe 4.0 M.2 slot for ultra-fast NVMe SSDs, along with multiple SATA ports for additional storage. It also offers advanced connectivity options such as WiFi 6E, 2.5GbE LAN, USB Type-C, HDMI, and DisplayPort, ensuring seamless network and device integration. The “ICE” edition features a clean white and silver design, perfect for all-white or minimalist builds. With EZ-Latch tool-free installation and Q-Flash Plus for easy BIOS updates, the B650M AORUS ELITE AX ICE combines high-end performance, efficiency, and elegance in a compact Micro-ATX form factor.

Write a review

Please login or register to review

What is the price of Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard in Bangladesh?

The latest price of Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard in Bangladesh is 25,999৳. You can buy the Gigabyte B650M AORUS ELITE AX ICE AM5 Micro-ATX Motherboard at the best price from our website or visit any of our showrooms.
