Gamdias HELIOS M1-500B 500W 80 Plus Bronze Power Supply
Key Features
- 500W continuous power for stable operation
- 80 Plus Bronze certified efficiency performance
- 120mm hydraulic fan ensures quiet cooling
- APFC technology improves power delivery stability
- Multiple protections safeguard valuable PC components
Specification
| General | |
| Brand | GAMDIAS |
| Model | HELIOS M1-500B |
| Key Features | |
| Certification | 80 PLUS Bronze |
| Efficiency (Approx.) | 80 Plus Bronze Certified 85% efficiency |
| Fan Size | 120mm hydraulic bearing fan |
| Others | Type: ATX12V v2.4 Power Factor Correction: APFC with PF value of 0.99 Protection: OVP / UVP / OPP / SCP / OCP |
| Connector | |
| CPU | 1 (4+4 Pin) |
| Main Power | 1 (20+4 Pin) |
| Molex | 2 (4 Pin) |
| PCI-E | 2 (6+2 Pin) |
| SATA | 4 (4 Pin) |
| Input | |
| Frequency Range | 47-63Hz |
| Voltage | 100-240V |
| Output | |
| AC Input | 180-240V~ / 8A / 47-63Hz |
| DC Output | +3.3V / +5V / +12V / -12V / +5Vsb |
| Modular Type | Non Modular |
| Peak Power | Max. Output Power: 100W / 444W / 3.6W / 12.5W |
| Total Power | 500W |
| Warranty Information | |
| Manufacturing Warranty | 6 Years |
Description
The Gamdias HELIOS M1-500B 500W 80 Plus Bronze Power Supply is a reliable and efficient power solution designed for budget and mid-range gaming PCs, office systems, and productivity builds. Delivering 500 watts of continuous power output, it is capable of supporting modern processors and entry-level to mid-range graphics cards with stable and consistent performance. The power supply carries an 80 PLUS Bronze certification, providing up to 85% power efficiency, which helps reduce energy consumption, heat generation, and operating costs. Equipped with a 120mm hydraulic bearing cooling fan, the HELIOS M1-500B automatically adjusts fan speed according to system temperature and load, ensuring quiet and effective cooling during operation. It features Active Power Factor Correction (APFC) with a power factor of up to 0.99, improving power stability and efficiency. Comprehensive protection mechanisms including OVP, UVP, OPP, OCP, and SCP safeguard connected components against electrical issues, making it a dependable choice for everyday computing and gaming systems. With multiple connectors including PCIe, SATA, and CPU power connectors, the HELIOS M1-500B offers excellent compatibility for a wide range of PC configurations.
