ARKTEK AK-H110M EG 7th Gen Micro-ATX Motherboard
Key Features
- Supported CPU: Intel 7th Gen Core i7/ i5/ i3/Pentium/Celeron (LGA1151)
- Supported RAM: 2x DIMM, DDR4 2133 MHz Max. 16GB
- Graphics Output: 1 x VGA, 1 x HDMI
- Features: Realtek RTL8105E 10/100 Mbps
Specification
| General | |
| Brand | ARKTEK |
| Model | AK-H110M EG |
| Memory | |
| Type | DDR4 |
| Slots | 2 x Memory Slots |
| Maximum Memory | up to 16GB |
| Supported Memory | 2133 MHz |
| Graphics | |
| Graphics | Integrated Graphics Processor-Intel HD Graphics support |
| Basic Information | |
| Audio | Chip integrated by Realtek 661 on board, Supports 6-channel audio-out |
| Chipset | Intel H110 Chipset |
| Form Factor | Micro-ATX (19.7 x 17 cm) |
| Supported CPU | Intel Socket 1151 for 7th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors Supports Intel 14 nm CPU |
| Expansion Slots | |
| PCI | 1 x PCI Express x16 slot |
| Ports & Connector | |
| Audio | 3 x Audio jack |
| HDMI | 1 x HDMI |
| Internal I/O Ports | 2 x USB 2.0 header supports additional 4 USB 2.0 ports 1 x USB 3.0 header supports additional 2 USB 3.0 ports 1 x Front Panel Audio header |
| LAN Port (s) | On board Realtek RTL8105E 10/100 Mbps adaptive network card interface |
| Supported Storage | 4 x SATA port |
| USB (s) | 2 x USB 2.0 port 2 x USB 3.0 port |
| VGA (s) | 1 x VGA port |
| Warranty Information | |
| Manufacturing Warranty | 2 years |
Description
The ARKTEK AK-H110M EG 7th Gen Micro-ATX Motherboard is designed to support Intel Socket 1151 processors, specifically catering to 7th Generation Core i7, Core i5, Core i3, Pentium, and Celeron processors. It utilizes the Intel H110 chipset and supports Intel 14 nm CPUs. The ARKTEK AK-H110M EG Motherboard features integrated graphics processing, supports DDR4 memory, and provides LAN connectivity and audio functions. It offers four SATA ports for storage devices and includes various I/O ports for connections. With its micro-ATX form factor and secure mounting holes, the AK-H110M EG is suitable for compact PC builds and is compatible with multiple Windows operating systems.
