Arctic P9 Max 92mm High-Speed PWM Casing Fan
Key Features
- Fan Speed: 450 – 4300 rpm (PWM controlled)
- Airflow: 58.25 cfm, 98.97 m³/h
- Static Pressure: 6.17 mmH2O
- Fan Bearing: Fluid Dynamic Bearing
Specification
| General | |
| Brand | Arctic |
| Model | P9 Max |
| Key Features | |
| Air Flow | 58.25 cfm | 98.97 m³/h |
| Bearing Type | Fluid Dynamic Bearing (FDB) |
| Input Current | 0.34 A |
| Size | 92 (L) x 92 (W) x 25 (H) mm |
| Fan Speed | 450–4300 rpm (PWM controlled), 0 rpm below 5 % PWM |
| Air Pressure | 6.17 mmH2O |
| Connector | 4-Pin Connector |
| Operating voltage | 12 V DC |
| Physical Specification | |
| Color | Black |
| Weight | 84g |
| Warranty Information | |
| Manufacturing Warranty | 06-year Warranty |
Description
The Arctic P9 Max 92mm High-Speed PWM Casing Fan is designed to provide powerful cooling in a compact dimension without sacrificing efficiency or control. This Arctic P9 Max 92mm PWM Casing Fan can reach an astounding 450 to 4300 rpm using PWM control and can drop to 0 rpm below 5 percent PWM, giving builders complete control over silence and performance at all times. The Arctic P9 Max 92mm Casing Fan has a powerful airflow rating of 58.25 cfm (98.97 m³/h), making it suitable for systems with limited airflow space. Its 6.17 mmH2O static pressure pushes air through dense components, radiators, and tight cooling zones, improving reliability for gaming rigs, office PCs, and compact workstations. The Arctic P9 Max Casing Fan incorporates a fluid dynamic bearing, which reduces noise, ensures smooth rotation, and promotes long-term endurance. This Arctic Casing Fan operates on a standard 12 V DC input, has a 5 V DC startup voltage, and draws 0.34 A of current. It remains consistent even under severe loads. The 400 mm cable allows for flexible routing, and the standard 4-pin fan socket is compatible with the majority of recent motherboards and fan hubs. The Arctic P9 Max 92mm High-Speed PWM Casing Fan is built to withstand high temperatures and restricted airflow while remaining responsive via PWM changes, making it an excellent choice for builders seeking stability and quick cooling in compact setups.
