VIEWSONIC TD2223 22 INCH 75HZ TN TOUCH MONITOR
Specification
| General | |
| Brand | VIEWSONIC |
| Model | TD2223 |
| Display Features | |
| Display Size | 22 Inch |
| Display Type | LED |
| Panel Type | TN |
| Refresh Rate | 75Hz |
| Resolution | FHD (1920 x 1080) |
| Response Time | (Typical GTG): 5ms (GTG w/OD): 5ms (Typical Tr+Tf): 5ms |
| Aspect Ratio | 16:9 |
| Display Surface | Glossy, Hard Coating (7H) |
| Viewing Angle | 170º horizontal, 160º vertical |
| Brightness | 250 cd/m² (typ) |
| Contrast Ratio | Static Contrast Ratio: 1,000:1 (typ) Dynamic Contrast Ratio: 20M:1 |
| Pixel pitch(MM) | 0.248 mm (H) x 0.248 mm (V) |
| Color Support | Colors: 16.7M Color Space Support: 8 bit (6 bit + Hi-FRC) Color Gamut: NTSC: 72% size (Typ), sRGB: 103% size (Typ) |
| Color Gamut | 72% NTSC 103% sRGB |
| Curvature | Flat |
| Others | Digital Sync: TMDS - DVI-D, TMDS - HDMI (v1.4) Analog Sync: Separate/Composite/SOG - RGB Analog |
| Audio Features | |
| Speaker Details | 2Watts x2 |
| Speaker (Built In) | Yes |
| Connectivity | |
| USB Port(s) | USB 2.0 Type A x 2 USB 2.0 Type B x 1 |
| VGA | VGA x 1 |
| HDMI | HDMI 1.4 x 1 |
| Audio Jack | 3.5mm Audio In x 1 3.5mm Audio Out x 1 |
| Mechanical Design | |
| Security Locker | Kensington Lock Slot |
| Tilt | 20º / 40º |
| Ports & Connector | |
| DVI-D (s) | DVI-D x 1 |
| Power | |
| Type | Internal |
| Power Consumption | Consumption (typical): 12.5W Consumption (max): 14W |
| Voltage | AC 100-240V, 50/60 Hz |
| Video Features | |
| Color Temperature Selection | 32°F to 104°F (0°C to 40°C) |
| Flicker Free | Yes |
| Low Blue Light | Yes |
| Physical Specification | |
| Color | Black |
| Weight | Net (lbs): 9.9 Net Without Stand (lbs): 8.6 Gross (lbs): 13.2 Net (kg): 4.5 Net Without Stand (kg): 3.9 Gross (kg): 6 |
| Dimension | Packaging (in.): 22.8 x 15.9 x 6.5 Physical (in.): 20.5 x 13.1 x 4 Physical Without Stand (in.): 20.5 x 12.5 x 2.4 Packaging (mm): 580 x 405 x 164 Physical (mm): 521 x 334 x 101 Physical Without Stand (mm): 521 x 318 x 61 |
| Other Features | |
| Other Features | Cover Glass Thickness: 2mm Viewable Area (in.): 21.5 Backlight Life (Hours): 30000 Hrs (Min) |
| Warranty Information | |
| Warranty | 2 Years Warranty |
Description
ViewSonic TD2223 22 Inch 75Hz IR Touch Monitor
The ViewSonic TD2223 22 Inch 75Hz IR Touch Monitor is an intuitive, multi-touch interactive display engineered for retail point-of-sale (POS) terminals, commercial kiosks, educational environments, and interactive office workflows in Bangladesh. Featuring a 21.5-inch Full HD ($1920 \times 1080$) resolution display with Infrared (IR) touch technology, it supports up to 10-point multi-touch tracking—allowing users to tap, pinch, swipe, and write seamlessly using fingers, gloved hands, or the included stylus pen.
Constructed to withstand heavy public use and demanding commercial environments, the TD2223 screen is protected by an anti-glare 7H scratch-resistant glass coating, ensuring exceptional durability without sacrificing touch sensitivity. A 75Hz refresh rate and a 5ms response time deliver smooth touch feedback and clear visual performance across everyday applications. The display is complemented by built-in dual 2W stereo speakers, providing instant audio playback without requiring external desktop speakers.
Designed for maximum operational flexibility, the ViewSonic TD2223 features an adjustable ergonomic bookstand design that allows the monitor to tilt from $20^\circ$ up to $40^\circ$ for comfortable tabletop touch interaction. It boasts a comprehensive connectivity panel—including HDMI, DisplayPort, VGA, and USB 2.0 downstream ports—ensuring broad compatibility with Windows, Android, Chrome, and Linux systems. Eye-care features such as Flicker-Free technology and a Blue Light Filter prevent eye fatigue during long operational shifts.
Buy ViewSonic TD2223 22 Inch 75Hz IR Touch Monitor in BD from Skyland BD
Get the original ViewSonic TD2223 22 Inch 75Hz IR Touch Monitor at the best price in Bangladesh from Skyland BD. Order online or visit our showroom to experience 10-point IR touch responsiveness, 7H scratch-resistant glass, integrated speakers, and versatile HDMI/DP/VGA connectivity today. The ViewSonic TD2223 Touch Monitor comes backed by a 3-Year Warranty.
